Club 3D ATI Radeon 9550SE 128 MB
Club 3D ATI RADEON 9550 SE 128MB
Artikelnummer: 004883
Beschreibung
Name / Brand / Architecture |
|
| Manufacturer: | Club 3D |
| Model: | Radeon 9550 SE |
| Part number: | CGA-S958TVD |
| Based on: | ATI Radeon 9550 SE [Compare] |
| Target market segment: | Desktop |
| Die name: | RV350 |
| Fabrication process: | 130 nm |
| Transistors: | 76 million |
| Bus interface: | AGP 8x |
Frequency |
|
| Graphics clock: | 250 MHz |
Memory specifications |
|
| Memory size: | 128 MB |
| Memory type: | DDR |
| Memory clock: | 190 MHz |
| Memory clock (effective): | 380 MHz |
| Memory interface width: | 64-bit |
| Memory bandwidth: | 3.04 GB/s |
Cores / Texture |
|
| Color ROPs: | 4 |
| Pixel shader processors: | 4 |
| Vertex shader processors: | 2 |
| Texture units: | 4 |
| RAMDACs: | 400 MHz |
| Decoders: | MPEG-1/2/4 |
Video features |
|
| Multi-monitor: | Up to 2 displays |
| Maximum VGA resolution: | 2048 x 1536 |
| Anti-Aliasing technologies: | 6 x MSAA Temporal AA |
Performance |
|
| Pixel fill rate: | 1.0 Gigapixels/s |
| Texture fill rate: | 1.0 Gigatexels/s |
External connectors |
|
| Standard display connectors: | DVI-I S-Video VGA |
Dimensions |
|
| Width: | Single-Slot |
Other features / Support |
|
| OpenGL support: | 2.0 |
| DirectX support: | 9.0 |
| Pixel shader model: | 2.0 |
| Vertex shader model: | 2.0 |
